Mondraker Chaser R – Dirty White/Black
The Mondraker Chaser R – Dirty White/Black is the perfect e-mountain bike for your off-road adventures. With its Zero Suspension System, Fox 36 Float FIT GRIP EVOL Rhythm fork, and Bosch Performance Line CX Cruise motor, you’ll be able to tackle any terrain with ease. Plus, the integrated dropout speed sensor and Bosch Powertube 750Wh battery will keep you going for miles. Get ready to take your riding to the next level with the Mondraker Chaser R – Dirty White/Black!
$10,999.00
Specifications
| 01. FRAME | Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery |
| 01A. FRAME | Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive p |
| 02. FORK | Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload |
| 03. REAR SHOCK | Fox Float DPS Performance, 205x65mm. Settings: Compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
| 04. SHOCK SETTINGS | medium compression, medium rebound, air volume spacer 0.4 |
| 05. HEADSET | Onoff Saturn tapered for 1-1/8″ to 1-1/2″ head tube, ACB sealed bearings, top 41×30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree |
| 06. STEM | Onoff Sulfur FG 30mm 0 degree, 6061 forged alloy, 31.8mm barbore |
| 07. HANDLEBAR | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore |
| 08. GRIPS | Onoff Twin, 1lock-on, 135mm |
| 09. SEATPOST | Onoff Pija dropper internal, diameter 31.6mm, S size: 405×95-125mm, M size 458×120-150mm, L size: 498×140-170mm, XL size: 498×140-170mm |
| 10. SADDLE | MDK ebike black |
| 11. FRONT BRAKE | Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| 12. REAR BRAKE | Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| 13. BRAKE LEVER | Sram DB8, tool-free reach adjust |
| 14. FRONT HUB | Mavic, Boost 15x110mm, IS 6 bolts |
| 15. REAR HUB | Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts |
| 16. FRONT TIRE | Maxxis Rekon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
| 17. REAR TIRE | Maxxis Rekon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
| 18. CRANKSET | Race Face Aeffect ebike, 165mm |
| 19. RINGS | Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD |
| 20. PEDALS | N/A |
| 21. CHAIN | Sram SX Eagle, 12s, Powerlock |
| 22. REAR DERAILLEUR | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| 23. CASSETTE | Sram PG-1210, 11-50T, 12s |
| 24. MOTOR | Bosch Performance Line CX Cruise (25Km/h) Smart System |
| 25. BATTERY | Bosch Powertube 750Wh |
| 26. DISPLAY | Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller |
| 27. DERAILLEUR HANGER | Mondraker M068 |
| 28. SIZES | S: 380mm / M: 420mm / L: 450mm / XL: 490mm |
