Mondraker F-Podium Carbon R - Carbon/Green/Silver
Mondraker F-Podium Carbon R - Carbon/Green/Silver
Mondraker F-Podium Carbon R - Carbon/Green/Silver

Mondraker F-Podium Carbon R – Carbon/Green/Silver

Experience the ultimate in XC performance with the Mondraker F-Podium Carbon R! This sleek and stylish bike is packed with features to help you take your riding to the next level. It features a F-Podium 29 Stealth Air Full Carbon frame with XCO Optimized Zero Suspension System, Fox 34 Step Cast Float FIT4 EVOL Factory Kashima fork, Fox Float DPS SV EVOL Factory Kashima rear shock, and Mavic Boost hubs. Plus, it comes in a stunning Carbon/Green/Silver colorway that will turn heads on the trails. Get ready to take your XC riding to the next level with the Mondraker F-Podium Carbon R!

$9,999.00

Specifications

01. FRAME F-Podium 29 Stealth Air Full Carbon, XCO Optimized Zero Suspension System, 100mm, XC Forward Geometry, Carbon Monoblock upper link
01A. FRAME BSA bottom bracket, tapered head tube, HHG internal cable routing, dedicated 1X drivetrain design, Boost 12x148mm rear axle, shock mudguard, postmount rear brake mount.
02. FORK Fox 34 Step Cast Float FIT4 EVOL Factory Kashima, 110mm, tapered steerer tube,15x110mm Boost axle, offset 44mm. Settings: remote 2pos Push-unlock, compression micro-adjustment at low-speed, rebound, a
03. FORK REMOTE Fox dual pull
04. REAR SHOCK Fox Float DPS SV EVOL Factory Kashima, 185×47,5mm. Settings: 2 position remote compression (open/lock), low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
05. SHOCK SETTINGS Firm compression, light rebound, air volume spacer 0.2
06. HEADSET Acros AZX-239 R1 Block Lock, ZS44/28.6 top, ZS56/40 bottom
07. STEM MDK, 6061 T6 Alloy, 31.8mm barbore, rise: /-5 degree, length: sizes S/M: 50mm, size L: 60mm, size XL: 70mm
08. HANDLEBAR Onoff Helium Carbon 0.2, rise: 4.8mm, width: 760mm, 9 degree backsweep, 0 degree upsweep, 31.8mm barbore
09. GRIPS Onoff Desert, 1lock-on, 135mm
10. SEATPOST Onoff Helium Carbon 0-R, diameter 31.6mm, length 400mm
11. SADDLE Fizik Antares R7
12. FRONT BRAKE Sram Level TL, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
13. REAR BRAKE Sram Level TL, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
14. BRAKE LEVER Sram Level TL, Direct Link actuation, tooled reach adjust, lever pivot bushings
15. FRONT HUB Mavic, Boost 15x110mm, IS 6 bolts
16. REAR HUB Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, XD freehub
17. FRONT TIRE Maxxis Rekon Race 29×2.35, EXO protection, tubeless ready, 120TPI, folding bead
18. REAR TIRE Maxxis Rekon Race 29×2.35, EXO protection, tubeless ready, 120TPI, folding bead
19. CRANKSET Sram X1 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S size: 170mm, M/L/XL size: 175mm
20. RINGS 34T, CNC-machined alloy, X-SYNC 2
21. BOTTOM BRACKET Sram DUB BSA, sealed bearings, 73mm
22. PEDALS N/A
23. CHAIN Sram GX Eagle, 12s, Powerlock
24. REAR DERAILLEUR Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
25. CASSETTE Sram XG-1275, 10-50T, 12s
26. DERAILLEUR HANGER Sram UDH
27. SIZES S: 390mm / M: 420mm / L: 470mm / XL: 510mm
